    SINOTRUK HOWO A7 Fuel Tanker Truck For Transportation 18000L Volume Φ430 Clutch

    SINOTRUK HOWO-A7 6x4 Fuel Tank Truck with 18000L volume and HW19710 transmission


    Description:


    HOWO brand Dump Truck is produced by SINOTRUK.Adopt A7-W Lengthen cab single bunk,new type seat,adjustable steering wheel.EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner.

    Adopting full hydraulic transmission, it can bring the power of engine into full play amply.Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.Rich experience and well after-sale service.


    Packing:


    Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.


    Competitive Advantage:


    1. Support service:response quickly in 12 hours and provide professional technical

    2. Shipping:professional transport team,safety and quickly

    3. The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.Warranty: one year

    4. Production time: within 35 working days

    5. Logistic team, can cargo your truck fast and safety.


    SINOTRUK HOWO 6x4 FUEL TANK TRUCK SPECIFICATIONS
    Cubage

    Tank volume: 18m³ 18000L(2C with Two compartment)
    head 5mm, body 5mm, material Q235
    Pump Flow: 40m³ / h

    Flow meter: return to zero flow meter

    Refueling gun: 1 inch
    Reel: 1 inch * 10 meters
    Other: pressure unloading, gravity unloading, towing wire, fire caps, fire extinguishers. Vehicle spray wax.

    Weight in kgKerb weight (Kg)12290
    Gross vehicle weight (Kg)30000

    Dimension(mm)


    Dimensions(mm)Length(mm)10300
    Width(mm)2550
    Height(mm)3250
    Wheel base (mm)4600+1350
    PerformanceMaximum driving speed (km/h)92
    Fuel consumption (1/100 km)38
    CabModel

    SINOTRUCK A7-W Lengthen cab

    single bunk,new type seat,adjustable steering wheel,EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner

    EngineModelWD615.69(Euro 2)
    Type6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection
    Horsepower336 Hp
    Maximum output Kw/r/min247/2200
    Maximum torque N.m/r/min1350/1300-1600
    Bore x Stroke126x130mm
    Valve2
    Displacement9.726L
    Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 80℃ opening begin, Rigid fan
    TransmissionSINOTRUK HW19710 transmission ,10 forward and 2 reverse
    ClutchSINOTRUCK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance
    SteeringZF8118 Steering Gear Box ,hydraulic steering with power assistance.(Left hand driving)
    Front AxleSINOTRUK HF9 Front Axle,new 9-ton front axles of equipped with drum brakes.
    Rear AxlesSINOTRUK HC16 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:4.8;The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.
    Brake System

    Service brake:dual circuit compressed air brake

    Parking brake (emergency brake):spring energy,compressed air operating on rear wheels

    Wheels & TyresRims:10 hole-steel ;Tyres:12.00R20 radial tyre with 1 Spare tire.
    Electrics

    Operating voltage:24V,negative grounded

    Starter:24V,7.5 Kw

    Alternator:3-phase,28V,1500 W

    Batteries:2x12 V,165 Ah

    horn,headlamps,fog lights,brake lights,indicators and reverse light

    Oil TankSquare type-400L Aluminum alloy fuel tank
