    HW19710 Transmission Tractor Trailer Truck Left Hand Driving Type ZZ4257N3247N1B

    Ask Lasest Price
    Brand Name : HOWO A7
    Model Number : ZZ4257N3247N1B
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 500 units/month
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    HW19710 Transmission Tractor Trailer Truck Left Hand Driving Type ZZ4257N3247N1B

    ZZ4257N3247N1B SINOTRUK HOWO EURO II tractor truck with HW19710 transmision


    Description:


    HOWO 6x4 Euro 2 tractor truck now is the best products in overseas market, the frame adopt U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members

    Front suspension adopt 10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer.Rear suspension adopt 12 leaf semi-elliptic springs, bogie spring and stabilizer.Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.


    Packing:
    Nude Pack.The packing of the products be suitable for long distance transportation of ocean and inland.Our take measures to against moisture,shocks and rust according to the special needs of the commodity.The main machine nude, attached parts and tools put into standard export box.Within 20 days deliver the goods to main Port.Ro-Ro ship or bulk ship or according to customer requiring.
    We have professional forwarding partners.

    Competitive Advantage:


    1. Flexible and convenient logistic service.
    2. Excellent and high-quality control

    3. Rich experience and well after-sale service.

    4. Long lasting working life time.
    5. Sufficient storage.

    6. Professinal Sales Team of trucks. Our target is not selling trucks, we help customers choose the best suitable trucks.
    7. Fast production period, and quick arrangement of delivery.


    Description:


    Sinotruk Howo A7 6x4 Tractor Truck
    Chassis ModelZZ4257N3247N1B (Left Hand Driving Type)
    CabinA7-P cab, with one sleeper and two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn,air conditioner, with transverse stabilizer, with 4-point support fully floating suspension + shock absorber.
    Engine

    Make: SINOTRUK

    Diesel 4-stroke direct injection diesel engine

    Engine model: WD615.47, Euro 2, 371 HP

    6-cylinder in-line with water cooling, turbo-charging and intercooling

    Displacement: 9.726 L

    TransmissionHW19710, 10F & 2R.
    SteeringZF8098, hydraulic steering with power assitance
    Front Axle

    HF9, 1x9000 KGS

    Steering with doubleT-cross section beam

    Rear Axle

    HC16, 2x16000 KGS, drum brake equipped with ABS system.

    Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles.

    Ratio:4.42

    Propeller ShaftDouble universal joint propeller shaft with gear-shaped coupling flange
    Chassis

    Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members

    Front suspension:10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer

    Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer

    Brake

    Service brake: dual circuit compressed air brake

    Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels

    Auxiliary brake: engine exhaust brake

    Electrics

    Operating voltage: 24 V, negative grounded

    Starter: 24 V, 5.4 Kw

    Alternator: 3-phase, 28 V, 1500 W

    Batteries: 2 x 12 V, 165 Ah

    Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light

    Tyres12.00R20, tubeless tires with 1 spare tires.
    Fuel Tank400L
    Overall Dimension6985x2550x3800 mm
