    Strong Gradeability XCMG Mobile Crane / 55 Ton All Terrain Crane Four Wheel Drive

    Ask Lasest Price
    Brand Name : XCMG
    Model Number : RT55
    Certification : CCC/ISO/CE
    Price : Negotiation
    Supply Ability : 1000 units per month
    Delivery Time : 25-30 work days
    • Product Details
    • Company Profile

    Strong Gradeability XCMG Mobile Crane / 55 Ton All Terrain Crane Four Wheel Drive

    High Quality ZOOMLION 55ton all terrain crane RT55 for sale


    Features:

    1. Max.loading:55t
    2 Engine:160KW

    3. Max.lifting height:56.4m
    4. Kessler axle
    5. 4*4 drive

    6. Crab steering,2 wheel steering,4 wheel steering

    7. Wheel base 3950 mm,allowing convenient steering in narrow space


    Advantages:

    Maneuverable and robust drive

    • Four-wheel drive and four-wheel steer chassis;
    • Fully hydraulic steering system;
    • Variable steering modes, front-wheel steer,four-wheel steer and crab steer;
    Short vehicle length and small turning radius provide the crane with maximum maneuverability and flexibility in narrow job sites

    Excellent off-road capability
    Big ground clearance and departure / approach angle offer excellent off-road capability.

    Strong gradeability
    Cummin electronically-controlled engine, automated transmission and steerable drive axlex provide reliable power output.
    Even in the condition of abrupt road resistance,the engine can also be functional.
    Four-wheel drive, hydraulic suspension and special tires optimize the vehicle’ s drive performance to its maximum

    Pick-and-carry operations
    The rough terrain crane has the ability to pick and carry loads, thus improves the working efficiency greatly.

    The crane can also carry out ”On tires“ Lifts without extending the outrigger beams in narrow job sites.
    Superior pick-and-carry ability during short-distance transit can bring great convenience to the users.

    Single cab design
    Single cab design with large skylight provides large field of view;
    Air-cushioned seat suits to all types of figures, which can release the driver’ s or operator’ s fatigue
    The crane is fitted with air conditioning, suitable for all-weather work;
    Digital display and keyboard units,advanced data bus technology,error check


    Main Parameters:


    TypeSer. No.ItemUnitValue
    Working performance1Max. rated lifting weight × working radiuskg.m55000×3.0
    2Max. lifting moment of basic boomkN.m1967
    3Max.lifting moment of longest boomkN.m1126
    4Max. lifting height of longest boomm34.8
    5Max. lifting height of jibm52.4
    Dimensions6Outline dimensions (L×W×H)mm13100×3300×3750
    7Distance between outriggers (Longitudinal × transversal)mm6900×6900
    8Main boom length (completely retracted – completely extended)mm10800~34000
    9Jib length (completely retracted – completely extended)mm10000~17000
    10Main boom angle of elevation°-3~78
    11Swing range360°continuously
    Working speed12Max.speed of single rope on the drum of main winchm/min150
    13Boom extension times100
    14Boom retraction times80
    15Boom derricking up times56
    16Boom derricking down times63
    17Swing speedr/min0~2.5
    Hydraulic system18Rated working pressureMPa27
    19Rated working flowL/min400
    20Hydraulic oil tank capacityL700
    Mass21Complete vehicle kerb masskg39200
    22Front axle loadkg20440
    23Rear axle loadkg18760
    Traveling24Max. traveling speed (forwards / backwards)km/h39/15
    25Wheelbasemm3950
    26Treads (front / rear)mm2605
    27Max. gradeability%75

    Products Photos:

    Strong Gradeability XCMG Mobile Crane / 55 Ton All Terrain Crane Four Wheel DriveStrong Gradeability XCMG Mobile Crane / 55 Ton All Terrain Crane Four Wheel DriveStrong Gradeability XCMG Mobile Crane / 55 Ton All Terrain Crane Four Wheel DriveStrong Gradeability XCMG Mobile Crane / 55 Ton All Terrain Crane Four Wheel Drive

    Working Site Overseas:

    Strong Gradeability XCMG Mobile Crane / 55 Ton All Terrain Crane Four Wheel Drive

    FAQ

    Q: Are you original manufacturer?

    A: Yes, we XCMG are a official leading manufacture in construction machinery in China and we have the whole series products you need.


    Q: Which payment terms are available to us?

    A: T/T term or L/C term. On T/T term, 30% down payment is required in advance, and 70% balance shall be settled before shipment. On L/C term, a 100% irrevocable L/C without "soft clauses" can be accepted.


    Q: Which Incoterms 2010 terms can we work?

    A: We XCMG are a professional and international company, accept all Incoterms 2010 terms, normally we work on FOB, CIF, CFR, CIP.


    Q: How long will the delivery time take?

    A: Normally it will take about 30-40 days to produce the ordered machines. Most of the time, we can have an immediate delivery of our regular machines in 20 days.


    Q: How about AFTER-SALES SERVICE ?

    A: 365×24 Year-round Service

    Globally, we have more than 5000 service engineers and 1500 dedicated service vehicles. We are committed to year-round 24-hour service even during holidays, in line with our policy of always providing "a response within 15 minutes and job completion within 24 hours."


    Smart Butler Service

    We have established a perfect GPS Global Service Center, and we can provide you with a proactive smart butler system through an Internet of Things platform.


    Spare Parts When You Need Them

    We have thousands of spare parts centers across five continents that stock almost 1 billion specialist spare parts. We promise that spare parts will be delivered within 72 hours.


    After-market Worry-free Service

    We are committed to providing after-market services, including rentals, second-hand vehicle evaluations, trade-ins, overhauls, and recycling. We always stick to our responsibility and mission of handling your concerns as best we can.


    Quality warranty

    We grant our clients a fourteen-month or 2000-hours warranty for any machine purchased from us.
