    HOWO WD615.47 6x4 Mining Dump Truck With HW19712 Transmission ZZ3257N3847A

    Ask Lasest Price
    Brand Name : HOWO
    Model Number : ZZ3257N3847A
    Certification : ISO/CCC
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 500 units/month
    Delivery Time : 30-45 Work days
    • Product Details
    • Company Profile

    HOWO WD615.47 6x4 Mining Dump Truck With HW19712 Transmission ZZ3257N3847A

    ZZ3257N3847A HOWO WD615.47 6x4 Mining dump TRUCK with HW19712 Transmission


    Description:


    1. Adopt HW76 Cab single bunk,new type seat,adjustable steering wheel

    2. EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner.

    3. Adopting full hydraulic transmission, it can bring the power of engine into full play amply.

    4. Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.

    5. Rich experience and well after-sale service.


    Packing:


    Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.


    Competitive Advantage:


    1. EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner.

    2. Adopting full hydraulic transmission, it can bring the power of engine into full play amply.

    3. Long standing reputation in this field.
    4. Specialization ,standard and accurate meet your requirement.

    5. The price is competitive.

    6. Excellent and high-quality control


    DimensionsLength (mm)8600
    Width (mm)3000
    Height (mm)3985
    cargo body size(mm):5800×2800×1600
    Cargo beam steel thicknessBottom 12mm, Side10mm
    Wheel Base (mm)3800+1500
    Front /rear suspension(mm)1500/1000
    Turning diameter(m)17
    PerformanceMax. Speed (km/h)75
    Max. Speed (km/h)(design)75
    Maximum Gradeability(%)43
    Approach/departure angle( ° )32/40
    EngineModelWD615.47
    Rated Power (HP/r/min)371HP/273kw, 2200r/min
    Max. Torque (Nm/r/min)1900/1100-1600
    TypeSINOTRUK
    Driving axleTypeHC16 strengthen steel two wide body reduction drive axle.
    ClutchModelStandard B-type (Standard WABCO clutch master cylinder,wheel cylinder)
    TypeSINOTRUK 430 pull-type diaphragm clutch
    TransmissionTypeHW19712, Max.torque1900Nm Assembly HW19710 gearbox, power take off with HW50, HW70 also available with power take off
    Speed12 gears
    FrameType & Advantages
    Adopt unilateral high-strength frame cab, modeling simple, tough, vision;
    Front AxleTypeSINOTRUK MADE, HF10 New front axle uses an enhanced wide-body resistance welded box beam front axle, more suitable for mining
    use harsh working conditions.
    Ratio Load(kg)1000
    FR. SuspensionTypeNew SINOTRUK style, spring suspension
    RR. SuspensionTypenormal leaf spring - multiple leaf spring
    SteeringModelZF8118
    TypeZF steering ,ZF power steerig pump,
    Steering Wheelhydraulic steering
    Service brake:dual circuit compressed air brake,
    Brake SystemParking brake:spring energy, compressed air operating on rear wheels,
    Auxiliary brake:engine exhaust valve brake
