    Commercial 371 HP 8x4 Diesel Dump Truck , Sand Dump Truck Q235 Steel Body

    Ask Lasest Price
    Brand Name : SINOTRUK HOWO
    Model Number : ZZ3317N4667A
    Certification : CCC/ISO9001/CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 5000 UNITS/Mouth
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    Commercial 371 HP 8x4 Diesel Dump Truck , Sand Dump Truck Q235 Steel Body

    HOWO 371 HP 8x4 Dump Truck 12 wheels with German ZF8118 Steering Gear Box


    SINOTRUK HOWO 8x4 Dump Truck Specifications

    Body

    Carriage Internal Dimensions(mm)8000x2300x1500
    Cubage (m3)27.6
    Steel thickness of Carriage(mm)Floor:8mm/Side:6mm
    SteelQ235
    Hydraulic Lift of CarriageFront Lift

    Weight in kg

    Kerb weight (Kg)10460
    Gross vehicle weight (Kg)31000

    Dimension(mm)



    Dimensions(mm)

    Length(mm)10315
    Width(mm)2496
    Height(mm)3125
    Wheel base (mm)1800+4600+1350
    Angle( ̊ )Approach14
    Departure33

    Performance

    Maximum driving speed (km/h)82
    Fuel consumption (1/100 km)46

    Cab

    ModelSINOTRUK HW76 Low-floor Lengthen cab
    HW76 cab, (single sleeping, with air-condition), all-steel forward control,70̊ hydraulically tiltable to the front,2-arm windscreen wiper system with 3 speeds,laminated windscreen with casted-in radio aerial,hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat,with heating and ventilating system,outer sun visor,adjustable roof flap,with stereo radio/cassette recorder,safety belts and adjustable steering wheel,air horn,with 4-point support fully floating suspension and shock absorbers.

    Engine

    ModelWD615.47(Euro 2)
    Type6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection
    Horsepower371
    Maximum output Kw/r/min274/2200
    Maximum torque N.m/r/min1460/1300-1600
    Bore x Stroke126x130mm
    Valve2
    Displacement9.726L
    Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 80℃ opening begin, Rigid fan
    TransmissionSINOTRUK HW19710 transmission ,10 forward and 2 reverse

    Clutch

    SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance

    Steering

    ZF8118 Steering Gear Box ,hydraulic steering with power assistance.(Left hand driving)

    Front Axle

    SINOTRUK HF9 Front Axle,new 9-ton front axles of equipped with drum brakes.
    SuspensionFront overhang1500mm
    Rear overhang1360mm

    Rear Axles

    SINOTRUK AC16 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:5.45;The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading.

    Brake System

    Service brake:dual circuit compressed air brake

    Parking brake (emergency brake):spring energy,compressed air operating on rear wheels

    Wheels & TyresRims10 hole-steel
    Tyres12.00R20 radial tyre with 1 Spare tire.
    Wheel tread2022/2022,2041/2041,1830/1830mm

    Electrics

    Operating voltage:24V,negative grounded

    24V,7.5KW.Starter:24V,7.5 Kw

    28V,1500W.Alternator:3-phase,28V,1500 W

    2x12V,165Ah.Batteries:2x12 V,165 Ah

    horn,headlamps,fog lights,brake lights,indicators and reverse light

    Oil TankSquare type-300L Aluminum alloy fuel tank

    Description:HOWO 8x4 Dump Truck is produced by SINOTRUK.And exported more than eighty countries and regions,for example Ethiopia,Kenya,South Africa,The Philippines,Saudi Arabia,Malaysia,Nigeria,Peru,Russia... It is suitable for in normal roads and tough roads, to transport and unload transport, stone, ore, and others loose materials, which is the best choice for heavy construction vehicle customers.

    Our advantages:

    1. Warranty: one year or 10000 km

    2. Production time: within 35 working days

    3. After-sale service team:highly trained with overseas working experience

    4. Support service:response quickly in 12 hours and provide professional technical

    5. Shipping:professional transport team,safety and quickly
