    ZF8118 Steering Gear Box 25 Ton Dump Truck , U Shape Heavy Duty Tipper Trucks

    Ask Lasest Price
    Brand Name : HOWO A7
    Model Number : ZZ3257N3647A
    Certification : ISO/CCC
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 500 units/month
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    ZF8118 Steering Gear Box 25 Ton Dump Truck , U Shape Heavy Duty Tipper Trucks

    ZZ3257N3647A HOWO A7 Euro 2 Black color U-type dump truck 371HP with HW76 cab


    Description:


    HOWO brand Dump Truck is produced by SINOTRUK.The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.The engine adopt 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection.Adopting full hydraulic transmission, it can bring the power of engine into full play amply.Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.Rich experience and well after-sale service.


    Packing:


    Nude Pack.The packing of the products be suitable for long distance transportation of ocean and inland.Our take measures to against moisture,shocks and rust according to the special needs of the commodity.Rich experience and well after-sale service.


    Competitive Advantage:


    1. Adopt HW76 Cab single bunk,new type seat,adjustable steering wheel

    2. EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner.

    3. Adopting full hydraulic transmission, it can bring the power of engine into full play amply.

    4. Technique support and training.

    5. Customization service, as per your request, we will customize our production for you


    TypeHOWO A7 dump truck
    ModelZZ3257N3647A
    Overall dimension8214x2496x3450 mm
    Cargo body size5600x2300x1600 mm
    Cargo thicknessBottom:8mm, Side:6mm
    Lift type of CarriageMiddle lifting or fornt lift
    Loading weight25 ton
    Wheel base3625+1350mm
    Drive model6x4
    EmissionERUO2
    Horsepower371HP
    Front axleHF9
    Rear axleHC16
    Tyre12.00R20
    Oil tank400L
    CabHW76 cab, single sleeping, with air-condition), all-steel forward control, 70° hydraulically tiltable to the front, 2-arm windscreen wiper system with 3 speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers.
    Colorblack
    SteeringZF8118 Steering Gear Box ,hydraulic steering with power assistance.(Left hand driving)
    Brake system

    Service brake:dual circuit compressed air brake

    Parking brake (emergency brake):spring energy,compressed air operating on rear wheels

    Electrics

    Operating voltage:24V,negative grounded

    24V,7.5KW.Starter:24V,7.5 Kw

    28V,1500W.Alternator:3-phase,28V,1500 W

    2x12V,165Ah.Batteries:2x12 V,165 Ah

    horn,headlamps,fog lights,brake lights,indicators and reverse light
