    8.8 Tons 300m Depth Pile Drilling Machine Crawler Type Pneumatic Drilling Rig FY300

    Ask Lasest Price
    Brand Name : HuaxiaMaster
    Model Number : FY300
    Certification : ISO
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 500 units / per month
    Delivery Time : 35 work days
    • Product Details
    • Company Profile

    8.8 Tons 300m Depth Pile Drilling Machine Crawler Type Pneumatic Drilling Rig FY300

    FY300 crawler type pneumatic drilling rig for rock is quick and high efficiency


    Products Description:


    Lifting force; patent design composite big arm, big arm small volume, long stroke, double cylinder lifting, lifting tonnage;Each rig hoisting arm installed limiter, safety protection cylinder, ensure safe work;Each hydraulic tubing are all covered with a protective sleeve, so that the pipe with longer service life.Very flexible in difficult roads and can be widely used in many fields such as resource exploration of hydrology wells, coalbed methane, the shallow layer of shale gas, terrestrial heat, etc, and can also be used for coal-mine gas exploitation salvage work.

    The top-mounted driving head principal shaft has a great drift diameter, suitable for many kinds of construction work such as slurry drilling, air drilling, and air foam drilling, meeting the demands for well-drilling at different terrain strata.Adopt patent diesel engine air inlet regulating device . That strengthens the crawler drilling rig’s adaptability to severe environment and lengthened the diesel engine’s service life.

    Packing:


    Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.


    Competitive Advantage:


    1. Guangxi Yuchai 85Kw turbocharged engine;
    2. Walking device: walking motor with gear box, high durability and long service life;
    3. Hydraulic oil pump; parallel gearbox design (patent) oil pump monomer separation, power supply adequate distribution reasonable, hydraulic system unique design, simple maintenance, small cost;
    4. Power head device, gearbox integrated casting, dual motor power, torque, durability, small maintenance costs;
    5. Drill chassis; professional excavator chassis, durable, high bearing weight, chain plate width, small damage to the hard surface;

    6. Each hydraulic tubing are all covered with a protective sleeve, so that the pipe with longer service life.


    Product Description:


    ModelFY300
    Gross weightT8.8
    Dimensionmm4350x1850x2750
    Aperturemm140-325
    Drilling depthm300
    Feed strokemm6000
    Travel speedkm/h2
    Grade abilityMax.30°
    Rising height from groundmm230
    Wind pressureMpa1.7-3.3
    Air consumptionm³/min23
    Engine powerkw85
    Rotary speedrpm55-115
    Rotation torqueN.m7200-8500
