    SINOTRUK HOWO A7 Mobile Concrete Mixer Truck 336 HP With 9.726L Displacement

    Ask Lasest Price
    Brand Name : SINOTRUK HOWO A7
    Model Number : ZZ1257N3841W
    Certification : ISO/CCC
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 1000 units/month
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    SINOTRUK HOWO A7 Mobile Concrete Mixer Truck 336 HP With 9.726L Displacement

    SINOTRUK HOWO A7 336 HP 6x4 Concrete mixer truck with 9.726L Displacement

    Description:


    SINOTRUK HOWO A7 6×4 Concrete mixer truck adopt HW76 Cab single bunk,new type seat,adjustable steering wheel,EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner.

    Adopting full hydraulic transmission, it can bring the power of engine into
    full play amply. Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.


    Packing:


    The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland.The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.


    Competitive Advantage:


    1. The satisfied product with high level standard.

    2. The full aspect service from order to shipping.

    3. Give customer most suitable advice when customer has special needs for your transportation or construction.

    4. Specialized in this area more than 10 years,rich experience and well after-sale service.

    5. Technique support and training. Customization service, as per your request, we will customize our production


    Configuration:


    SINOTRUK HOWO A7 336 HP 6x4 Concrete mixer truck with 9.726L Displacement

    Main description
    Overall Dimensions8840mm×2495mm×3800mm
    Tare Weight11860kg
    Front Overhang1500mmRear Overhang2365mm
    ColorOptionalGross of weight30000kg
    Wheelbase3800mm+1350mmTrack (F/R)2022mm/1830mm
    Chassis
    Chassis BrandSINOTRUK HOWO A7
    Chassis ModelZZ1257N3841W, driving type 6x4
    CabHW76( left hand drive, air-conditioner, one sleeper)
    EngineSINOTRUK WD615.69, 336hp, Euro II emission standard,6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection, displacement 9.726L
    Gear BoxHW15710, 10 forward and 2 reverse
    Traversing MechanismGerman ZF8118, hydraulic steering with power assistance
    Rear AxleST16 tandem axle, ratio 5.73
    Wheels and tires12.00R20, 10 units with one spare wheel
    Brakes

    Service brake: Dual circuit pneumatic brake;

    Parking brake: Spring energy, compressed air operating on rear wheels;

    Auxiliary brake: Engine exhaust brake


    Electrics

    Operating voltage:24V,negative grounded

    24V,7.5KW.Starter:24V,7.5 Kw

    28V,1500W.Alternator:3-phase,28V,1500 W

    Batteries:2x12 V,165 Ah

    horn,headlamps,fog lights,brake lights,indicators and reverse light

    Mixing system
    Mixing Volume8cbm
    Water Tank Volume400L
    Mixing DrumBody steel plate thickness 6mm, Front end thickness 8m
