    High Efficiency Construction Concrete Mixing Equipment Full Hydralic Control

    Ask Lasest Price
    Brand Name : SINOTRUCK
    Model Number : SW3500
    Certification : CCC/CE/ISO
    Price : Negotiable
    Payment Terms : LC / TT
    Supply Ability : 5000 UNITS/Month
    Delivery Time : 30-35 work days
    • Product Details
    • Company Profile

    High Efficiency Construction Concrete Mixing Equipment Full Hydralic Control

    New model 3.5m3 Self Loading Concrete Mixer SW3500 Construction Machine


    Brief Description:


    Self-loading concrete cement mixer is the combination of concrete mixer truck and cement mixer, which can automatically feed, measure, mix and discharge concrete mixture. Equipped with a powerful engine and 4 wheel steering, the self loading concrete mixer is just like a small car and the operator can drive it to where it needs to go. It is very convenient for loading material, such as cement, aggregate, stone. The raw material is scattered in the construction site.


    Advantages

    1) Saving time and labor

    2) Saving concrete transporting cost

    3) Mobile and highly motorized on site, more efficient

    4) Low maintenance cost

    5) High reliable and durable

    6) Easy operation and high intelligent

    7) Closed circuit hydraulic system, more powerful and reliable.


    Performance:

    Mobile self-loading concrete mixer

    4X4X4 concrete mixer

    Reliable,high-performance

    Drum capacity:5.3m³

    Output:3.5m³


    Products Specs:


    SW3500 Specifications
    MIXING UNITDrum capacity 5.3M3. Concrete output: 3.5 M3 per batch. Double mixing screws, cover for emergency unloading. Drum rotation by hydraulic motor and planetary reducers. Mixing and discharging speed indipendent from r.p.m. of diesel engine. Discharging by reversing drum. The mixing unit is slewing hydraulically through 270° for high discharge over 1.8 m to the four sides of the vehicle.
    ENGINEYuchai YC4A125Z,diesel,water-cooled,4 cylinders. Rated power 92kw/2200rpm.
    TRANSMISSIONFull hydraulic driving. 4 wheel drive and 4 wheel steering. hydraulic Pump and motor are connected to the differentials through reducer. 4X4X4
    SPEEDLow: 0-10km/h, high: 0-20km/h
    DRIVING SEATFront cab on side of loading shovel.
    HYDRAULIC SYSTEMTwo circuits. 2 Plunger pumps for walk and drum rotation. 2 gear pumps for services. Inlet and outlet filter. Heat exchanger water/oil-air type.
    JOYMIXAll hydraulic functions of shovel controlled by a single - fully servo controlled Joystick.
    LOADING SHOVELCapacity 650 liters, complete with hydraulic opening gate.
    CHUTESlewing. Fitted with two pins easily detachable to increase the discharge height.
    WATER SYSTEMSelf-contained. Hydraulic driven water pump, water meter. High pressure water pump & washing gun
    GRADIENTFully loaded 30%
    BRAKESHydraulic brakes,Twin indipendent circuits. Hydraulic parking brake
    TYRESConstruction tyres 16/70-20.
    STEERINGHydraulic. 3 way steering.
    ELECTRIC SYSTEM24V. Safety battery cut-off.
    TANKSWater: 2x350 liters. Diesel: 165 liters. Hydraulic oil: 150 liters.
    CHASSISSteel profile specially engineered for off-road operations.
    OVERALL DIMENSIONSLong: 7.2M width 2.5M high: 3.3M
    WEIGHT8600kgs, equally distributed on both axles
    SAFETYMachine equipped with checking and block valves for maximum safety of the operator.
    MEASURING SYSTEMElectronic weating system

    Construction Photos:

    High Efficiency Construction Concrete Mixing Equipment Full Hydralic ControlHigh Efficiency Construction Concrete Mixing Equipment Full Hydralic ControlHigh Efficiency Construction Concrete Mixing Equipment Full Hydralic ControlHigh Efficiency Construction Concrete Mixing Equipment Full Hydralic Control


    Our services:

    Warranty: one year

    Including one year spare parts together with machine. In the first year, spare parts free. Freight belongs to buyer. Freight in China belongs to seller.
