    GR180 Large Cab Road Building Equipment / Road Grading Equipment Hydraulic System

    Ask Lasest Price
    Brand Name : Others
    Model Number : GR180
    Certification : ISO/CCC
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 1,000 units per month
    Delivery Time : 35 work days
    • Product Details
    • Company Profile

    GR180 Large Cab Road Building Equipment / Road Grading Equipment Hydraulic System

    GR180 360° Swing angle of balde Construction Machinery Road Grader with 16L Open-type system

    Description:

    A grader, also commonly referred to as a road grader or a motor grader, is a construction machine with a long blade used to create a flat surface during the grading process. Although the earliest models were towed behind horses or other powered equipment, most modern graders contain an engine so are known as "motor graders".Control System adopt 7 position link bar with electric over hydraulic control allows ease of operation from within the cab.Optimum blade reach capability, quick DCM re-positioning for greater reach for better working on high bank side slope.The link bar is essential for extending reach capability when cutting a bank slope or back slope of a ditch.Replaceable bushings reduce service time and cost.Blade Float adopt standard blade float function allows blade to lower without hydraulic pressure for increased versatility.Blade float is engaged by pushing the left and right lift cylinder controls all the way forward past the detent.Provides protection for machine and pavement during snow removal and snow plowing

    Packing:

    Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.

    Features:

    1. Hydraulic System:Proportional Priority Pressure Compensating (PPPC) Valves contain specifically cut spools for motor grader applications, continuously matching of hydraulic flow and pressure to power demands, allowing ease of multi-function control for optimizing working efficiency

    2. Drawbar:A-frame tubular design drawbar provides maximum strength and durability.Replaceable drawbar draft ball (bolted - not welded) for less service time and cost

    3. Front Frame:Flanged box section design removes welds from high stress areas, improving reliability and durability.Continuous top and bottom plate construction provides consistency and strength, improving front frame durability

    4. Control Layout:Short throw levers are efficiently spaced, allowing ease of multi-function control.Short lever travel (40mm) with low lever effort reduces operator fatigue

    5. Large Cab:High performance dashboard with 3 levels alarming monition system.Cab mounted on the front frame provides exceptional view to blade and front axle even during articulation


    Specifications:
    T1000 vibration construction machinery road roller compactor

    Overall dimensionL×W×H8900×2700×3500mm
    Mini ground clearance of front axle560mm
    Ground clearance of rear axle500mm
    Wheel tread1685mm
    wheel base6840mm
    Length of blade3952mm
    Wheelbase of rear axles1650mm
    EngineBrandCummins 6BTA5.9-C160
    Rated power/speed180hp/2400
    Certified capacity6.75L
    Minimum fuel consumption rate≤230g/(kw.h)
    Overall parametersOverall weight15000kg
    Max.swinging angle of front axle±16°
    Ma.steering angle of front wheel±45°
    Steering angle of articulated frame±25°
    Cutter diameter1500mm
    Cutter size(L×H×T)3952×590×20mm
    Swing angle of balde360°
    Ground clearance of blade450mm
    Cutting depth of blade360mm
    Incination angle of bladeForward 47°/backward 5°
    Sliding range of bladeLeft 600/right 600mm
    Hydraulic systemTypeOpen-type system
    System pressure16L
    Fill capacityFuel220L
    Hyfraulic oil140L
