    Red 4WD Agriculture Farm Tractors With 3 Point Suspension And Double Stage Clutch JM-254

    Ask Lasest Price
    Brand Name : Nonghaha
    Model Number : JM-254
    Certification : CO
    Price : Negotiable
    Payment Terms : LC/TT.
    Supply Ability : 300 units per month
    Delivery Time : Within 15 working days
    • Product Details
    • Company Profile

    Red 4WD Agriculture Farm Tractors With 3 Point Suspension And Double Stage Clutch JM-254

    JM-254 Red color 4WD agricultural farm tractor with 3-Point Suspension and Double stage clutch


    Description:


    The Agriculture Farm Machinery is developed on the basis of the Italian wheeled tractor chassis technology, adopting the British technology-based 6-cylinder turbocharged engine. The machine body has a streamline configuration. It is low in specific fuel consumption and better in power economic efficiency. It has multiple gears and a wide speed range. Besides, it is flexible in steering and easy to operate.


    Packing:

    Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.


    Competitive Advantage:


    1. Specially used in mountain areas and muddy roads;

    2. 4 in1 combined light is used in the front, and modular lights can provide good lighting at night;

    3. It has the characteristics of high transmission efficiency, low tremble, high traction, high adaptability and easy start;

    4. Hydraulic output interface can make direct connection with the dump trailer, mower, backhoe, plough, etc;

    5. This series of tractor can have many different configurations according to customer’s demands.

    Specifications:


    Model

    JM-254


    Drive Type

    4WD



    Dimensions

    3080x1440x1930


    Wheel Tread(mm)

    Front

    1100

    Rear

    1040-1200

    Wheel Base(mm)

    1645


    Ground Clearance (mm)

    295


    Rated Traction Force(N)

    5980


    Construction Mass(kg)

    1140


    Min.Turning Radius(m)

    2.80


    Theoretical Speed(Without creeper)

    km/h)

    Forward

    1.73,2.64,4.14,5.71,8.01,12.20,19.14,26.40

    Reverse

    2.28,11.02


    Engine



    Model

    KM385BT

    Type

    3-Cylinder Vertical,water cooled,4 stroke cycle

    Rated Power(kw/hp)

    18.4/25

    Rated Speed (rpm)

    2350

    Bore×Stroke(mm)

    85×90

    Total Displacement(L)

    1.532


    Drive System

    Clutch

    Double stage

    Gear Box

    (4+1)×2

    Main Drive

    One Pair of Spiral Bevel Gearing

    Differential

    Bevel Gear

    Differential Lock

    Jaw Lock

    Final Transmission

    External gearing, Spur Gear


    Traveling Mechanism

    Front

    6.00-16

    Rear

    9.5-24

    Steering Gear

    Hydraulic Steering

    Brake

    Disc type


    Working Device

    Lifting Capacity at 610mm Behind Lift Point (N)

    4200

    3-Point Suspension

    Category:I

    Speed (rpm)

    540/1000

    Spline Size

    6-∮35Rectangular spline
