    HOWO 70T Mining Tipper Truck / Off - Road Dump Truck ZZ5707S3840AJ

    Ask Lasest Price
    Brand Name : SINOTRUK HOWO 70
    Model Number : ZZ5707S3840AJ/ZZ5707S4040AJ
    Certification : CCC
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 500 units per month
    Delivery Time : 60 days
    • Product Details
    • Company Profile

    HOWO 70T Mining Tipper Truck / Off - Road Dump Truck ZZ5707S3840AJ

    Product Details
    HOWO 70T Mining Tipper Truck/SINOTRUK mining dump truck/ CNHTC HOWO dump truck/ Special truck / off-road dump truck
    Chassis ModelZZ5707S3840AJ,ZZ5707S4040AJ,ZZ5707S4840AJ,ZZ5707V3640CJ,ZZ5707V3840CJ,ZZ5707V4040CJ,ZZ5707V4840CJ
    Driving Type6X4
    CabinHW7D cab, without sleeper and two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer, with 4-point support fully floating suspension + shock absorbe
    EngineMake: SINOTRUK
    Diesel 4-stroke direct injection diesel engine
    Engine model: WD615.47T2, 371 HP ;D12.42T2,420;
    Emission :Euro 2
    6-cylinder in-line with water cooling, turbo-charging and intercooling
    Displacement: 9.726 L
    TransmissionHW21712, 12F & 2R, with PTO
    SteeringZF power steering, modol ZF8118, hydraulic steering with power assitance
    Front Axle

    HF12,1x12000 KGS

    Steering with doubleT-cross section beam

    Rear AxleAC26, 2x26000 KGS
    Pressed axle housing, central single reduction with hub reduction,with differential locks between wheels and axles.
    Ratio:10.47,8.51
    Propeller ShaftDouble universal joint propeller shaft with gear-shaped coupling flange
    Chassis
    Front suspension: 1500mm,Half the elliptical leaf spring with shock absorber cavitation
    Rear suspension: 1000mm, The overall balance shaft balance suspension, unilateral inclined outfit 4 riding bolt
    BrakeService brake: dual circuit compressed air brake
    Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels
    Auxiliary brake: engine exhaust brake
    ElectricsOperating voltage: 24 V, negative grounded
    Starter: 24 V, 5.4 Kw
    Alternator: 3-phase, 28 V, 1500 W
    Batteries: 2 x 12 V, 165 Ah
    Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
    Tyres14.00-25, radial tyres with one spare tyre
    Fuel Tank500L
    Cargo BodyLength:5.8M,6.3M,6.8M,7.6M;Width:3.1M;Height:1.2-2M
    Overall Dimension9045*3200*3770 mm

    HOWO 70T Mining Tipper Truck / Off - Road Dump Truck ZZ5707S3840AJHOWO 70T Mining Tipper Truck / Off - Road Dump Truck ZZ5707S3840AJ
