    Intelligent Road Maintenance Equipment With 8M3 Aggregate Bin 3M3 Emulsion Bitumen Tank

    Ask Lasest Price
    Brand Name : SINOTRUCK
    Model Number : ZZ1257N4641W
    Certification : CCC ISO
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 1000 units per month
    Delivery Time : 25-30 work days
    • Product Details
    • Company Profile

    Intelligent Road Maintenance Equipment With 8M3 Aggregate Bin 3M3 Emulsion Bitumen Tank

    Sinotruck Mirco-sufacing machine,slurry seal company,road building machine


    LMT5255TXF micro-surfacing equipment, as the special machinery for asphalt pavement construction, is developed by our company and can be widely used in the fast synchronous spraying work of highways. The asphalt and aggregate can be sprayed together or respectively. It has some positive features including cost-saving, surface wear resistance, anti-skidding, water proof and quick resumption of normal traffic after construction. It is suitable for the construction of the highways in different levels.


    Main feature:


    1.Hydraulic parts with imported brands

    2.Ensuring the machine with Hight reliability.

    3.Low the maintenance cost

    3.Top brand hydraulic strainer

    4.Using the big diameter spiral fabric structure

    5.with no dead corner,no segregation and second time mixing to low the system weight

    6.Easy to adjust the paving width meet the different.


    Main Technical Parameters


    No.NameQu-tyModelBrand /Country
    1Auxiliary Engine14BTA3.9 (97KW/2300RPM)USA / Cummins
    2Asphalt Pump1TG GM-80Belgium /JOHNSON
    3Hydraulic Pump63SPA29+3SPA22+2SPA11 SAEB NTUItaly/Hansa-TMP
    4Hydraulic Accessories1Parker, EatonUSA
    5Hydraulic Motor1MAT250CTaiwan / MAXMA
    6Vibrating Motor1MVE200DC -24China
    7Reduction Gear2MTKAVD-M22 /Switzerland / BUCHER
    8Main Electric Unit1SiemensGermany
    9Mixer11800-2000 Kg/minChina
    10Water Pump1FMC-200HYD-310USA / ACE
    11Flow divider1AM216SAE2RBD10SAEBItaly/Hansa-TMP
    5Cement and belt conveyor motor2TE0080AS260AABJUSA/ Parker
    6Paving box , asphalt pump motor3M0206AC23AG0200000000A00Italy/Hansa-TMP
    112" Asphalt flowmeter18041+8025+S020Germany Proudly
    121.5" Water flow meter 1.5 "18030+8025+S030Germany Proudly
    131/2" Additive flow meter 1 / 2 "18030+8025+S030Germany Proudly
    16Control system1Siemens componentsGermany
    17Stirring pot1MetongChina
    18Paving box1MetongChina

    Specification:


    CATEGORYITEMUNITPARAMETER
    Auxiliary engine systemModel/4BTA3.9
    Factory/Cummins
    Output powerkw/(r/min)97KW/2300RPM
    Drive mode/Hydraulic drive
    Emulsified asphalt systemEmulsified asphalt tankl4000
    Max. asphalt flowl/min250
    Measurement methods/The flowmeter Show / pump speed adjustment
    Asphalt pump insulation/Hot water
    Water systemWater boxl4000
    Max. water flowl/min300
    Measurement methods/The flow meter Show / pump speed adjustment/ Valve regulated

    Stone system


    Stone box12

    Conveyor bandwidth


    mm650

    Stone throughput/


    kg/min1700
    Adjustment method/The material door open degree
    Device to Prevent feeding clogging/DC vibration motor
    Cement systemCement silo0.5
    Cement throughputkg/min60
    Adjustment method/Screw speed adjustment
    Device to Prevent feeding clogging/Fork
    Additive systemAdditive tankl230
    Measurement methods/The flow meter Show / pump speed adjustment
    Stirring pot systemThe stirring abilityKg/min1800-2000
    Mixing form/Bi-axial strong stirring
    Paving box

    Paving Width


    m2.5--4.2
    Width adjustment method/Hydraulic telescopic adjustment
    Paving thicknessmm3--15
    The speed controller/Hydraulic adjustment
    Auxiliary stickle device/Stickle two times
    Cleaning systemCleaning method/High pressure cleaning
    Control systemPLC Microcomputer PLC/Siemens
    Control mode/Manual / automatic

    OTHERS


    Vehicle Dimensionsmm12240×2500×3650
    Wheelbasemm1350
    Traction pin diametermm90

    Intelligent Road Maintenance Equipment With 8M3 Aggregate Bin 3M3 Emulsion Bitumen TankIntelligent Road Maintenance Equipment With 8M3 Aggregate Bin 3M3 Emulsion Bitumen TankIntelligent Road Maintenance Equipment With 8M3 Aggregate Bin 3M3 Emulsion Bitumen Tank
