    Sinotruk HOWO 4x4 290hp Truck Mounted Crane 6.3 Ton Telescopic Boom 12.00R20 Tire

    Ask Lasest Price
    Brand Name : XCMG
    Model Number : SQ6.3SK3Q
    Certification : CCC BV
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 600 Unit/Units per Month
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    Sinotruk HOWO 4x4 290hp Truck Mounted Crane 6.3 Ton Telescopic Boom 12.00R20 Tire

    Sinotruk HOWO 4x4 290hp Truck Mounted Crane 6.3ton Telescopic Boom 12.00R20 Tire

    Product description


    1.Throttle Control System

    Changing the form of previous manipulation and throttle operation individually,Realization of the bilateral handle synchronous and driving throttle acceleration and deceleration automatically, due to the speed change steady,it can easily to carry out the lifting work.

    2.End position automatic hook device
    Maximum savings in preparation time before and after operation, to ensure that customer's vehicle could be in a driving state in the shortest time, and prevent crane damage accident caused by hoist swing to enhance the safety of driving.

    3.Hoisting overwinder device
    If a user is negligent or unfamiliar with the operation of lifting hooks,the hoisting overwinder device will stop hook raise in time, to prevent the safety of personal and property caused by fracture of wire rope.

    4.Slewing locking device
    Slewing locking device can ensure that the lifting arm does not sway because of the centrifugal force during the driving and steering process of the vehicle,to avoid all kinds of accidents caused by swaying.

    5.Torque limiter
    It can select torque limit overload protection device to prevent users because of negligence or unfamiliar with the lifting operation principle of overload operation, thereby causing the vehicle rollover and crane damage accidents.


    Product parameter


    Crane Parts
    Max Lifting Moment15.7TM
    Crane ModelSQ6.3SK3Q
    Max Lifting Capacity6.3T
    Rotation Angle(360°) all rotation
    Crane Weight2230 kg
    Flow of Hydraulic System40 L/min
    Pressure of Hydraulic System20MPa
    Oil Tank Capacity90L
    Installation Space1050mm
    Chassis Parts
    Truck ModelZZ5167M5227A (Left Hand Drive)
    Truck BrandSINOTRUK –HOWO
    Type of vehicleOff-road truck
    Engine Power290HP
    Traction 4x4 & 6x6 & 8x84x4
    Overall Dimension(Lx W xH)8968*2496*3370
    Approaching angle/Departure angle(°)32/36
    Overhang(front/rear) (mm)1500/2200
    Wheel base (mm)5200
    Max speed(km/h)75
    The total mass (kg)16 000
    Curb weight(kg)1010
    Caapacity of fuel tank (L)300
    Cargo body size (L*W*H, mm)5300x2300x600 bottom:3mm, side:1.5mm,

    Engine Model


    ModelWD615.87
    Horse Power290HP EURO II
    Fueldiesel
    TransmissionHW15710C 10 forwards and 2 reverse
    ClutchSingle-plate dry clutch Φ420mm
    Steering system8118
    Front axleSTR
    Rear axleST16
    ColorOptional
    Tire12.00R20 Radial tire 6+1 spare tire
    Cabin

    HW76

    single sleeper with air-conditioner


    Product picture
