    371HP 20CBM Heavy Duty Dump Truck With Yellow Color And HF9 Front Axle

    Ask Lasest Price
    Brand Name : HOWO
    Model Number : ZZ3257N3847A
    Certification : CC
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 300 Unit/Units per Month
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    371HP 20CBM Heavy Duty Dump Truck With Yellow Color And HF9 Front Axle

    Euro 2 SINOTRUK HOWO 371HP 20CBM 6x4 Dump Truck With Yellow Color And HF9 Front Axle


    Specification


    Vehicle seriesHOWO-7 6x4 Dump Truck
    CabHW76
    EngineModelEuro 2:WD615.47
    Power(Ps/rpm)273/2200
    Maximum torque(Nm/rpm)1500
    Displacement(L)9.726
    TransmissionSINOTRUK HW19710 series 10 gears Transmission,Transmission with main and auxiliary transmission structure, , main transmission with double counter shaft ,auxiliary transmission with planetary reduction.
    ClutchΦ430diaphragm spring Clutch,Hydraulic control air assisted.
    Front axleHF9 drum-type, rated load of 9t
    Rear axleHC16 double reduction (central reduction+wheel reduction),speed ratio:5.73, 4.8
    Steering systemZF8118 steering gear, ZF steering oil pump, system pressure 18MPa
    SuspensionSteer Axlefront and rear leaf spring suspension, front suspension with shock absorber,transverse stabilizer
    Drive Axlefront and rear leaf spring suspension,rear suspension is disconnected type with transverse stabilizer.
    Braking systemService brakedual-circuit air pressure brake
    Parking Brakespring storage energy without air
    Auxiliary brakeEngine exhaust braking.
    Electric systemVoltage24V
    Generator2240W
    Batteries12V/165Ah,2 pieces
    Starter Power24V,7.5kW
    Wheels & TyresTyres12.00R20
    Optional12.00R24,12.00-24
    Fuel TankCapacity300 Liter
    Weights (kg)Curb weight(vehicle/chassis)12170/8630;12290/8660;12450/8690;12270/8710
    Gross Vehicle Weight25000
    Rated load12420~12700
    Vehicle Dimensions (mm)Overall length x Overall width x Overall height(7545~8545)×2496×3170/3450
    Wheelbase(3225~3825)+1350
    Front/rear overhang(vehicle/chassis)1500/(1470/715);1500/(1670/740);1500/(1870/900)
    Wheel track of front axle2041
    Wheel track of rear axle1830/1850
    PerformanceMaximum speed(km/h)79/83
    Maximum gradeability(%)20
    Minimum turning diameter(m)15/16/17

    Description:


    HOWO 6x4 371 hp mining dump TRUCK is better than normal dumptruck.The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner.Adopting full hydraulic transmission, it can bring the power of engine into full play amply.Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.Rich experience and well after-sale service.


    Packing:


    Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.


    Competitive Advantage


    1.competive price, cost-effective
    2.with all kinds of truck model, which can fulfil your requirements

    3.all kinds of cargo body structure can be designed and produced according to your request,make it have light curb weight , high rigidity , high loading capacity
    4.using the high strength steel, make it has a long service life
    5.The optimized hydraulic control system helps to avoid wrong operation, it has higher safety and running efficiency.
    6.excellant apperance of cabin, safety, reliable

    7.quick and efficient spare parts supply bring you more convenient

    8. you can choose cargo body with Front lifting type or Middle lifting type which you prefered

    9. The hydraulic sytem using HYVA brand or Domestic famouse brand

    10.low fuel consumption
    11. strong enough engine

    12.fast delivery time, we can arange production according to your needs exactly and quickly

    13. professional import and export dealing precedure, make customs clearance more high efficiency
