    8L Concrete Construction Equipment / 9m3 Concrete Mixer Truck With Pump Self - Loading

    Ask Lasest Price
    Brand Name : SINOTRUK
    Model Number : ZZ1257M3247W
    Certification : ISO9001
    Price : NEGOTIABLE
    Payment Terms : L/C, T/T
    Supply Ability : 5000/MONTH
    Delivery Time : 15-45DAYS
    • Product Details
    • Company Profile

    8L Concrete Construction Equipment / 9m3 Concrete Mixer Truck With Pump Self - Loading

    SINOTRUK HOWO 6x4 9m3 concrete mixer truck with pump self-loading condition new


    Product Quick Details:


    Condition:New

    Place of Origin:Shandong, China (Mainland)

    Brand Name:SINOTRUK

    Model Number:Concrete Mixer Truck

    Warranty:6 Months

    Brand Name:HOWO

    Dimension(L*W*H):8700x2500x3965

    Certification:CCC,ISO9001

    After-sales Service Provided:Overseas service center available

    Supply Ability:3000 Unit/Units per Year

    Packaging Details

    Naked package,shipment by 20FT container, 40FT container,40FT high container,open-top container,flat bed container ,Ro-Ro ship or bulk ship according to the size of product.

    Port:Any port of China

    Lead Time :

    Quantity(Units)1 - 5>5
    Est. Time(days)30To be negotiated

    Product Features:

    1). Using hydraulic transmission device, do not rely on external force, easy to use, continuous rotation of the tank during transport, commercial concrete does not precipitate, not segregation.
    2). Easy to operate, a handle to achieve centralized control of mixing tank, the configuration mature and reliable, easy maintenance.
    3). Low noise, no smoke, safe and reliable.
    4). The use of high-intensity wear-resistant steel plate mixing tank, durable.
    5). Unique inlet setting, easy to spread material.
    6). Small size, transport flexibility, easy operation and maintenance, power consumption, energy-saving effect is remarkable.
    7). Blade design is reasonable, the discharge residue rate is low.


    What can you get from us?

    1. Get the new products, and meet your processing requirements.
    2. Our quality products help you to win money and earn much time.
    3. We always do our best to save cost for you and ensure the quality goods.
    4. Our rich-experience technical teams are standing by all the time.
    5. You can know the advance overseas technology from our products. Which bring you morecompetitive advantages.

    Product Specification:


    1)Low fuel consumption
    2)Comfort.safety.reliability
    3)mighty and beautiful modeling


    Complete vehicle
    Chassis modelZZ1257M3247W
    Steering typeLeft hand drive / Right hand drive
    BrandSinotruk HOWO
    Driving type6X4
    Wheel base(mm)3225+1350
    Overall dimension(mm)8700×2500×3965
    Curb weight(kg)12600
    Total weight(kg)25000
    CabHW76(Flat roof,one and half rows cabin,luxury configuration,A/C provided)
    EngineModelWD615.62
    Max.output (kw/HP)196/266
    Max.torque (N•m)1100@1100~1600 rpm
    Displacement (ml)9726
    Emission standardEuro 2
    Gear boxHW15710,manual,10 forward & 2 reverse gears
    Driving axleHC16,Ratio:5.73,max.load capacity 16000Kg*2
    Front axleHF9,max load capacity 9000Kg
    Steering gearGermany ZF8118
    Chassis suspensionNS-07new stabilizing suspension
    Air intake systemDouble pipe cyclone air duct+Oil air filter+Common air filter
    Inner trimming
    Standard configurationAir suspension seat
    Seat heater
    Lumbar support to the driver
    Adjustable steering wheel
    Sun roof
    Electrical system
    Standard configurationCAN bus intellectual electronic control system
    New battery box
    Start/stop device under the vehicle
    Safety

    Standard

    configuration

    Three points safety belt
    Automatic clearance adjustment arm,Tachometer
    Comfortable accessories
    Cab four points full floating suspensionFront and rear coil spring
    Standard configurationCab anti-rolling stabilizing device
    Hand accelerator
    Others
    Aluminum alloy fuel tankSquare-400L
    Standard configurationBig tool box
    Reinforced rim (with HQ mark)
    Three in one lock (ignition switch, door and fuel tank)
    Type specification11.00R20
    Number of tires10+1
    Mixer tank
    MaterialWISCO steel 16MnQ345
    ReducerItaly PMP
    Hydraulic pumpItaly PMP
    Hydraulic motorItaly PMP
    RadiatorChangzhou
    Tank capacity9m3

    8L Concrete Construction Equipment / 9m3 Concrete Mixer Truck With Pump Self - Loading8L Concrete Construction Equipment / 9m3 Concrete Mixer Truck With Pump Self - Loading

    Q. What is your payment terms ?
    A: 30% TT before produce and 70% TT before shipment . or 100% LC at sight ( irrevocable ).
    Q. How long time you could delivery goods to customer ?
    A : Generally 25 days of working , after we receive your deposits .
    Q:How you can ensure you have deliveried goods to customers ?

    A: We will give you the complete shipping information details for you confirmed .
    Q. How you could supply customers after sales services ?
    A: We will reply you at first time and help you resolve the problems within 24 hours . If it really need us to your local , we will send your professional person to your local to help you resolve problems without any hesitation , supply you all-around after-sales services including machine maintenance and operation and technical training services etc .
