    Hydraulic Roller Earth Compactor Machine XCMG 20 Ton XS203H 140 Kw 2130mm

    Ask Lasest Price
    Brand Name : XCMG
    Model Number : XS203H
    Certification : CE/ISO9001
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 1000 Unit/Units per month
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    Hydraulic Roller Earth Compactor Machine XCMG 20 Ton XS203H 140 Kw 2130mm

    XCMG Yellow 20 Ton XS203H Hydraulic Roller earth compactor machine 140 kw 2130mm

    Product Description

    The XS203H full-hydraulic single-drive vibratory roller is more comfortable to operate and offers superior compaction performance and efficiency.
    It is suitable for compaction operations such as concrete, stabilized soil, pebbles, sandy soil, and sticky soil. It is an ideal compaction device for the construction of high-grade highways, airports, ports, and embankments.
    Remarkable compacting performance
    Dual frequency and dual amplitude vibrating system and scientific and reasonable static linear load and excitation force ensure the effective compaction of different materials and layers with different thicknesses.
    Outstanding powertrain
    Hydraulic drive system: adopt the closed anti-slip hydraulic drive system composed by imported heavy-load variable pump and motor, ensuring the good driving performance and high gradeability.
    Reliable Electrical System
    The electrical system adopts imported water-proof, dust-proof, vibration-resistant electric connectors for increased reliability.
    Imported maintenance-free battery has high start-up current and good adaptability.

    Specification

    Description

    Unit

    Parameter value

    Work weight

    kg

    20000

    Drive wheel distribution weight

    kg

    10000

    Vibratory drum distribution weight

    kg

    10000

    Static line load

    N/cm

    470

    Vibration frequency

    Hz

    28/33

    Theoretical amplitude

    mm

    1.9/0.95

    Exciting force

    kN

    353/245

    Speed range Ⅰ

    km/h

    0-5.5

    Speed range Ⅱ

    0-8.5

    Wheelbase

    mm

    3180

    Compaction width

    mm

    2130

    Theoretical climbing ability

    %

    39

    Minimum turning radius

    mm

    6500

    Vibratory drum diameter

    mm

    1600

    Minimum ground clearance

    mm

    440

    Engine Model

    Model

    SC7H190G3

    Rated speed

    r/min

    2200

    Rated power

    kW

    140

    Dimensions

    mm

    6220×2430×3200

    Vibration system pressure

    MPa

    35

    Steering system pressure

    MPa

    38

    Drive system pressure

    MPa

    16

    Product Show

    Hydraulic Roller Earth Compactor Machine XCMG 20 Ton XS203H 140 Kw 2130mmHydraulic Roller Earth Compactor Machine XCMG 20 Ton XS203H 140 Kw 2130mmHydraulic Roller Earth Compactor Machine XCMG 20 Ton XS203H 140 Kw 2130mmHydraulic Roller Earth Compactor Machine XCMG 20 Ton XS203H 140 Kw 2130mm
