    Red Howo Waste Collection Truck , 6 - 19 Cubic Rubbish Compactor Truck

    Ask Lasest Price
    Brand Name : HOWO
    Model Number : CSC2019334
    Certification : ISO CCC
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 300 Unit/Units per Month
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    Red Howo Waste Collection Truck , 6 - 19 Cubic Rubbish Compactor Truck

    Howo Waste Collection Truck , 6 - 19 Cubic Rubbish Compactor Truck For Garbage Collect

    Product Description

    Garbage truck, include the several kinds of garbge collection truck. garbage compactor.garbage container truck.Arm-roll garbage truck, Arm shaking garbage truck,dump garbage truck,and so on.Currently we produce the garbage compactor truck from 4 m3 ~ 20 m3.Garbage container truck from 3~10 tons.Dump garbage truck from 3 m3~10 m3.

    1. The whole truck tank is sealed and the waste water come from the compression process will flow into the slop tank. At this point, our compactor trucks can solve the problem of secondary pollution when doing garbage transportation.

    2. Our garbage compactor truck is made up of sealed garbage tank, hydraulic system and control system.

    3. We adopt imported component to build important parts in our truck which have some advantages, such as high pressure, well-sealed, easy operation and safe.

    4. You can choose the suitable dumping gear when you are buying the truck.

    5. High automization: computer control system includes half and whole automation type, all load and unload work can be finished by the driver alone, thus can reduce working intensity and improve working condition.

    6. High reduction ratio and heavy load make our truck can carry twice garbage as heavy as other same-weight-level trucks which have no compress function.

    7. Energy saving: good energy saving when the equipment are working, throttle valve is controlled by computer.

    8. Dumping gear: you can choose garbage can or refuse hopper to be fixed into dumping gear.

    9. Double insurance system: our truck have automatic and manual work mode which can safeguard and raise the usage of trucks.

    Product Parameter

    Production name HOWO compactor garbage truck 16cbm
    Chassis model ZZ1257N4647C
    Type 6×4, Right/Left hand drive
    Weights
    Related weight (kg) 30000
    Curb weight (kg) 14000
    Dimensions
    Wheelbase(mm) 4600+1350
    Overall Dimension(mm) 10100×2500×3400
    Box dimension (mm) 16m3
    Max speed(km/h) 90
    Engine
    Engine model WD615 (336HP)
    Engine type 4 stroke water-cooled, inter-cooling
    No of cylinder straight-6 cylinders
    Displacement(L) 9.726L
    Max power(kw) 249kw
    Drive Line
    Transmission HW13710CL
    10 speeds,10 forwards,2 reverse gear,manual operation
    Steering ZF8098 Power steering
    Cab
    Cabin HW76 cab
    Configuration standard Air conditioner ,and so on
    Axles
    Front axles HF7
    Rear axles MCY13
    Tire specification
    Tire 12.00-20 standard tire,10 tires+1 spare tire
    Specification of compactor garbage truck
    Box valume 16m3
    Box material Side 4mm,bottom 5mm
    Sewage tanker 200L
    Fill volume 1.2cbm
    Loading time 20-30S
    The cycle time of the loading 50-60S/per turn
    Unloading model Dump
    Unloading time 40-50S
    Hydraulic system pressure 16Mpa

    Product Picture

    Red Howo Waste Collection Truck , 6 - 19 Cubic Rubbish Compactor TruckRed Howo Waste Collection Truck , 6 - 19 Cubic Rubbish Compactor TruckRed Howo Waste Collection Truck , 6 - 19 Cubic Rubbish Compactor TruckRed Howo Waste Collection Truck , 6 - 19 Cubic Rubbish Compactor Truck
