    Mechanical Suspension 60T Heavy Duty 500MM Dump Semi Trailers

    Ask Lasest Price
    Brand Name : SINOTRUK
    Model Number : SW
    Certification : CCC
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 500 units/month
    Delivery Time : 20 work days
    • Product Details
    • Company Profile

    Mechanical Suspension 60T Heavy Duty 500MM Dump Semi Trailers

    3 Axles 60 Tons Heavy Duty Dump Semi Trailers With 13 Tons FUWA Brand Axle And 500MM Beam Height


    Product description:


    1. Excellent and high-quality control
    2. Long lasting working life time.
    3. Suspension is usually American style,or german style
    4. Support legs also can be selected

    5. Axles usually is 2, 3
    6. Brand can be FUWA, BPW, also other brands for selection.

    7. We have been engaged in this industry for more than 20 years. High quality has always been our advantage.


    Packing:


    Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.


    Competition advantages:


    For Each trailer, we must do the testing and inspect the quality,and we have more than 30 QC&QA people on the production process and the testing process and warehouse to gurantee the quality of the every details.You wil get the inspection certificate according to customer demand for every trailer which given by an independent third party certification company. You will get the out-standing quality assurance.

    The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland.


    MAIN DESCRIPTION
    Overall Dimension9000×2500×3700mm
    Tare Weight8000kg
    Pay Load50 ton
    Axle Weight Load13 T
    RUNNING GEAR
    Suspension3 axle mechanical suspension with 10 pcs leaf spring ( Optional : air suspension )
    Axle13T (Optional : BPW )
    Rims & TiresRim 8.0-20
    BrakesDual lines pneumatic brake system, (Optional: ABS); 6 air chamber; parking brake
    UNDER FRAME
    Main Beam

    The height of the beam is 500mm,

    Upper plate: 14mm;

    Down plate: 16mm;

    Middle plate: 8+6mm;

    King PinWelded king pin, size 2'' or 3.5''
    Landing Gear28T Manual operating
    Spare Tire Carriers2 pieces
    CARGO BODY
    Steel sheetFloor thickness 6mm, side wall thickness 4mm
    Hydraulic JackFull set of HYVA hydraulic system, front setting telescopic jack
    TailgateOne-piece tailgate with upper articulation, safety lock system
    ELECTRICAL & PAINT
    Lights & ReflectorsRear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light
    Wiring24V, 6 lines
    Air / Electric. ConnectorISO standard air connector, 24V 7 pin plug socket
    PaintSand blasting before painting, color upon request
    Accessories2 sets standard tool box
