    HOWO 20cbm 4*2 Right Hand Drive 266HP Sewage Suction Truck

    Ask Lasest Price
    Brand Name : SINOTRUK
    Model Number : HOWO
    Certification : ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
    Price : Negotiate
    Payment Terms : L/C,T/T
    Supply Ability : 300 units/mouth
    Delivery Time : 40 worker days
    • Product Details
    • Company Profile

    HOWO 20cbm 4*2 Right Hand Drive 266HP Sewage Suction Truck

    HOWO 20cbm 4*2 Right Hand Drive 266HP Sewage Suction Truck

    Product Description

    HOWO 20cbm 4*2 Right Hand Drive 266HP Sewage Suction Truck


    1. Fecal Suction Truck Vacuum Tank Truck
    1.1 vacuum tank sewage suction truck is loading and discharging quickly.
    1.2. Fecal suction truck with 16cbm tank volume.
    1.3. Sewage suction truck is discharged clearly.

    2. Fecal Suction Truck Vacuum Tank Truck main equipment:
    sewage suction tank truck cab - single and half row, optional: A/C
    vacuum sewage truck Engine - sino howo, 6 cylinders
    vacuum truck manual gearbox -9-speed
    sewage truck drive axle loading capacity- 20T
    vacuum suction truck tire - 10.00-R20
    vacuum sewage sucking truck tank capacity - 16cbm

    3. Fecal Suction Truck Vacuum Tank Truck main specification:
    Sewage Suction Vacuum Truck Technical Specification
    Product NameSino howo
    SEWAGE SUCTION TRUCK
    Chassis ModelZZ1250
    Fuel typeDiesel
    Emission StandardEuro 2
    CabinHW16
    Whole Vehicle
    main dimensions (mm)
    Overall dimensions (LxWxH)9500*2400*3300
    Wheel baseoptional
    Min. ground clearance480
    Weight data (kg)G.V.W25000
    Curb weight1200
    Max payload16000
    Whole vehicle
    main performance
    Max. speed (km/h)95
    Max. slope of climb (%)30
    Engine


    ModelWD615 47
    Maximum power336HP
    Number of cylinders6
    Displacement (ml)9.726
    Gear boxModel9
    Number of gears9 forward gears &1 reverse
    AxleFront Load capacity (ton)7
    Rear Load capacity (ton)18
    Steering Wheelleft/right hand driveLHD,RHD
    Brake systemService brakeAir braking
    Electric deviceRated voltage24V
    Tyres&Quantity
    10.00-20& 6+1
    Sewage Suction Vacuum Truck Special Tank Description
    Tank

    Material:high quality carbon steel
    Structure:welding,vacuum tank,Cylindrical
    capacity(L)16000
    thickness of material6mm
    pump





    typevacuum pump
    model65QZ-40/45N
    flux(L/S)65
    rating speed(r/min)500
    shaft power(kw)4
    featuresLow speed,low fuel consumption,low noise,high vacuum,high efficiency
    manufactureHangzhou Weilong Pump Co.,Ltd,(Famous in China)
    pipe65-100mm suction and discharge pipe
    special functionsuction time ≤ 5min,
    effective suction range ≥ 8,
    max vacuum degree ≤ 15 Kpa,
    dump angle ≥ 45
    equipmentEquipped with power take off,transmission shaft,fecal tank, pipe network,fecal pipe for observing and cleanout equipment
    Time for full suction less than 5min
    hydraulic lift and lock discharge cover. sewage tube,vacuum pump,recovery,etc

    HOWO 20cbm 4*2 Right Hand Drive 266HP Sewage Suction Truck
